Cast iron filter press
Cast iron filter press is made of high quality cast iron or ductile iron, suitable for high temperature material filtering. High strength of filter plate is able to bear higher pressure andmaintain a longer service life. Widely used for solid-liquid separation in Petroleum chemical, metallurgy, oil, ceramics industries.
Description
Model | Area (m2) | Plate size (mm) | Cake thickness (mm) | Fiter (L) chamber volume | Plate Qty (pcs) | Frame Qty (pcs) | Filtration pressure (Mpa) | Weight (Kg) | Dimensions L×W×H(mm) | Foundation Size (mm) | |||
| L | B | D | H | ||||||||||
BMQ1/320-25 | 1 | 380×380 | ≥25 | 13 | 4 | 5 | 0.6 | 380 | 1150×760×650 | 700 | 150 | 650 | 460 |
| BMQ2/320-25 | 2 | 25 | 9 | 10 | 500 | 1390×760×650 | 940 | ||||||
BAQ3/320-25 | 3 | 38 | 14 | 15 | 620 | 1750×760×650 | 1300 | ||||||
BMQ4/450-25 | 4 | 500×500 | 51 | 9 | 10 | 0.6 | 1060 | 1780×870×880 | 1355 | 180 | 700 | 620 | |
BMQ6/450-25 | 6 | 76 | 14 | 15 | 1160 | 2055×870×880 | 1605 | ||||||
BAQ8/450-25 | 8 | 102 | 19 | 20 | 1360 | 2305×870×880 | 1855 | ||||||
BMQ12/450-25 | 12 | 152 | 29 | 30 | 1530 | 2785×870×880 | 2355 | ||||||
| BMQ16/450-25 | 16 | 203 | 39 | 40 | 1760 | 3305×870×880 | 2855 | ||||||
XAQ4/450-25 | 4 | 51 | 9 | 960 | 1900×870×880 | 1330 | 180 | 700 | 620 | ||||
XMQ6/450-25 | 6 | 76 | 14 | 1140 | 2030×870×880 | 1580 | |||||||
XMQ8/450-25 | 8 | 102 | 19 | 1460 | 2280×870×880 | 1830 | |||||||
XAQ12/450-25 | 12 | 152 | 29 | 1960 | 2780×870×880 | 2330 | |||||||
| XMQ16/450-25 | 16 | 203 | 39 | 2460 | 3280×870×880 | 2830 | |||||||
BMQ20/630-25 | 20 | 700×700 | 298 | 24 | 25 | 0.6 | 3300 | 2750×1150×1100 | 2270 | 400 | 1000 | 820 | |
BAQ30/630-25 | 30 | 452 | 37 | 38 | 4500 | 3220×1150×1100 | 2920 | ||||||
BMQ40/630-25 | 40 | 496 | 49 | 50 | 5600 | 3870×1150×1100 | 3570 | ||||||
| BMY20/630-25 | 20 | 298 | 24 | 25 | 3700 | 2960×1150×1100 | 2490 | 400 | 1000 | 820 | |||
BMY30/630-2 | 30 | 452 | 37 | 38 | 5000 | 3610×1150×1100 | 3140 | ||||||
BAY40/630-25 | 40 | 595 | 49 | 50 | 6100 | 4210×1150×1100 | 3740 | ||||||
XMQ20/630-25 | 20 | 248 | 24 | 3400 | 2600×1100×1100 | 2300 | 400 | 1000 | 820 | ||||
XMQ30/630-25 | 30 | 377 | 37 | 4700 | 3250×1100×1100 | 2950 | |||||||
XAQ40/630-25 | 40 | 496 | 49 | 5900 | 3900×1100×1100 | 3600 | |||||||
XAY20/630-25 | 20 | 248 | 24 | 3800 | 2950×1100×1100 | 2460 | 400 | 1000 | 820 | ||||
| XMY30/630-25 | 30 | 377 | 37 | 5200 | 3580×1100×1100 | 3110 | |||||||
| XAY40/630-25 | 40 | 496 | 49 | 6400 | 4180×1100×1100 | 3710 | |||||||
